TORISHIMA CENTRIFUGAL PUMPS
ETA.N series are industrial pumps of back pull out design according to JIS B 8313
OPERATING RANGE
Capacity Q Up to 620 m3/hr ( 170 l/s)
Total Head H Up to 100 m
Temperature T - 10 to 100 Degree Celsius
Pressure P Up to 10 bar
Pump Size 32 to 150 mm
APPLICATIONS
- General water supply, irrigation and drainage
- Pumping of sea water, brine, alkali and condensate
- Circulating hot and cold water supply
- Sprinkling & fire fighting system
- Swimming pool
DESIGN
- End suction volute pumps with vertical centerline discharge
- Back Pull Out (BPO) design allows the removal all rotating elements without disturbing the casing, piping or motor
MATERIAL EXPLANATION
Bronze or BC2 or BC6 quality is recommended for sea water application or other corrosive media
IMPELLER
- Closed, radial flow impeller fitted with protective wear ring
- Balanced hydraulically
- Trimming of impeller is possible
BEARING
- Permanent lubricated grease ball bearings
- Oil lubricated bearing pompa sentrifugal
